Danfoss Type NRV refrigeration check valves for Air conditioning 1/4'' 3/8'' 1/2'' 5/8'' 3/4'' 7/8''

Detalhes do produto:

Lugar de origem:	China
Marca:	BRANDO
Certificação:	None
Número do modelo:	NRV, NRVH

Condições de Pagamento e Envio:

Quantidade de ordem mínima:	5 unidades
Preço:	Negociável
Detalhes da embalagem:	Caixa interna, caixa, palete
Tempo de entrega:	Negociação
Termos de pagamento:	T/T, Western Union, Moneygram
Habilidade da fonte:	100.000 unidades por mês

Contato

Descrição de produto detalhada

Nome do produto:	Válvula de verificação da refrigeração	Tamanho da porta:	1/4", 3/8", 1/2", 5/8", 3/4", 7/8"
Conexão:	Em frente, Soldado.	Faixa de temperatura da mídia:	50°C a +140°C
Pressão máxima de trabalho:	46 bar	Líquido refrigerante aplicável:	HCFC, HCFC, HC
Destacar:	Danfoss nrv check valve , NRV refrigeration check valves , Check valve danfoss nrv

Danfoss Type NRV refrigeration check valves for Air conditioning 1/4'' 3/8'' 1/2'' 5/8'' 3/4'' 7/8''

NRV and NRVH refrigeration check valves can be used in liquid, suction and hot gas lines in refrigeration and air conditioning plant with HCFC. HFC and HC flammable refrigerants. The valves ensure the correct flow direction and prevent back-condensation from a warm part of the system to the cold evaporator. A built-in damping piston makes the valves suitable for installation in lines where pulsation can occur. e. g. in the discharge line from the compressor.

Technical Data of NRV, NRVH Straightway Solder Check Valve:

Model	Connection Type	Connection Size		Pressure drop across valve		Kv value	Cv value	Code no
Model	Connection Type	inch	mm	bar	psi	m3 /h	gal/min	Code no
NVR 6s	Straight-way, Solder	1/4''	-	0.07	1.01	0.56	0.65	020-1010
NVR 6s			6	0.07	1.01	0.56	0.65	020-1014
NVR 6s		1/4''	-	0.07	1.01	0.56	0.65	020-1057
NVR 6s			6	0.07	1.01	0.56	0.65	020-1050
NVRH 6s		3/8''	-	0.3	4.35	0.56	0.65	020-1069
NVRH 6s			10	0.3	4.35	0.56	0.65	020-1062
NVR 10s		3/8''	-	0.07	1.01	1.2	1.39	020-1011
NVR 10s			10	0.07	1.01	1.2	1.39	020-1015
NVRH 10s		1/2''	-	0.3	4.35	1.2	1.39	020-1046
NVRH 10s			12	0.3	4.35	1.2	1.39	020-1036
NVR 10s		1/2''	-	0.07	1.01	1.2	1.39	020-1058
NVR 10s			12	0.07	1.01	1.2	1.39	020-1051
NVRH 10s		1/2''	-	0.3	4.35	1.2	1.39	020-1070
NVRH 10s			12	0.3	4.35	1.2	1.39	020-1063
NVR 12s		1/2''	-	0.05	0.72	2.05	2.37	020-1012
NVR 12s			12	0.05	0.72	2.05	2.37	020-1016
NVRH 12s		1/2''	-	0.3	4.35	2.05	2.37	020-1039
NVRH 12s			12	0.3	4.35	2.05	2.37	020-1037
NVR 12s		5/8''	16	0.05	0.72	2.05	2.37	020-1052
NVRH 12s		5/8''	16	0.3	4.35	2.05	2.37	020-1064
NVR 16s		5/8''	16	0.05	0.72	3.6	4.16	020-1018
NVRH 16s		5/8''	16	0.3	4.35	3.6	4.16	020-1038
NVR 16s		-	18	0.05	0.72	3.6	4.16	020-1053
NVRH 16s		-	18	0.3	4.35	3.6	4.16	020-1065
NVR 16s		3/4''	19	0.05	0.72	3.6	4.16	020-1059
NVRH 16s		3/4''	19	0.3	4.35	3.6	4.16	020-1071
NVR 19s		-	18	0.05	0.72	5.5	6.36	020-1017
NVRH 19s		-	18	0.3	4.35	5.5	6.36	020-1008
NVR 19s		5/8''	19	0.05	0.72	5.5	6.36	020-1019
NVRH 19s		5/8''	19	0.3	4.35	5.5	6.36	020-1023
NVR 19s		7/8''	22	0.05	0.72	5.5	6.36	020-1054
NVRH 19s		7/8''	22	0.3	4.35	5.5	6.36	020-1066

Main Dimension of NRV, NRVH Straightway Solder Check Valve:

Model		Connection Size		L	L2	φD
Model		Inch	mm	mm	mm	mm
NRV 6s	NRVH 6s	1/4''	6	92	7	18
NRV 6s	NRVH 6s	3/8''	10	95	9	18
NRV 10s	NRVH 10s	3/8''	10	109	9	18
NRV 10s	NRVH 10s	1/2''	12	109	10	18
NRV 12s	NRVH 12s	1/2''	12	131	10	22
NRV 12s	NRVH 12s	5/8''	16	131	12	22
NRV 16s	NRVH 16s	5/8''	16	139	12	28
NRV 16s	NRVH 16s	-	18	139	14	28
NRV 19s	NRVH 19s	-	18	165	14	34
NRV 16s	NRVH 16s	3/4''	19	139	14	28
NRV 19s	NRVH 19s	3/4''	19	165	14	34
NRV 19s	NRVH 19s	7/8''	22	165	17	34
