This is a solenoid coil for BFEC pulse valve DMF-Z-20, DMF-Z-25, DMF-Z-40S, DMF-Z-50S, DMF-Z-62S, DMF-Z-76S, DMF-ZM-20, DMF-ZM-25, DMF-ZM-40S, DMF-Y-25, DMF-Y-40S, DMF-Y-50S, DMF-Y-62S, DMF-Y-76S, DMF-Y-102S; Voltage: 24VDC, 110VAC, 220VAC; Power: 20W, 25W; Connector: DIN 43650 Form A.
Pulse jet valves are indirect operated solenoid valves especially designed for dust collector systems. When the solenoid is energized, trapped air above a diaphragm is quickly exhausted causing a high pressure difference across the diaphragm. Thereby the diaphragm is suddenly opened. When the solenoid is de-energized, air escapes through a hole to the chamber above the diaphragm which balances the pressure and instantly closes the valve. The fast opening and closing of the valve is of great importance for effective cleaning of filters and economical consumption of compressed air.
Dimension & Data of BFEC Pulse Valve Coil & Armature:
BRANDO Model
BB13541204
Voltage
220VAC, 110VAC, 24VDC
Power
25W, 20W
Connector
DIN 43650 Form A
BRANDO Model
BAPC213050375
Guide Tube Material
Stainless Steel
Seal Material
NBR
Video of BFEC Pulse Valve Solenoid Coil:
BRANDO Solenoid Valve Coils Production Video:
More BFEC Pulse Valves for you to choose:
Right Angle Type
Quick Mount Type
Straight Through Type
Submerged Type
Diaphragm
Solenoid Coil
Solenoid Armature
Pulse Controller
