ASCO Type G353A045 G1-1/2'' Inch Remote Pilot Pulse Jet Diaphragm Valve

ASCO Type G353A045 G1-1/2'' Inch Remote Pilot Pulse Jet Diaphragm Valve

  • ASCO Type G353A045 G1-1/2'' Inch Remote Pilot Pulse Jet Diaphragm Valve
  • ASCO Type G353A045 G1-1/2'' Inch Remote Pilot Pulse Jet Diaphragm Valve
  • ASCO Type G353A045 G1-1/2'' Inch Remote Pilot Pulse Jet Diaphragm Valve
  • ASCO Type G353A045 G1-1/2'' Inch Remote Pilot Pulse Jet Diaphragm Valve
ASCO Type G353A045 G1-1/2'' Inch Remote Pilot Pulse Jet Diaphragm Valve
Detalhes do produto:
Lugar de origem: China
Marca: Brando
Certificação: CE
Número do modelo: G353A045
Condições de Pagamento e Envio:
Quantidade de ordem mínima: 1 unidade
Preço: Negociável
Detalhes da embalagem: caixas internas, caixas, paletes
Tempo de entrega: Negociação
Termos de pagamento: L/C, T/T, Western Union
Habilidade da fonte: 100000 PCs por mês
Contato
Descrição de produto detalhada
Tipo: Tipo válvula do ângulo direito de diafragma Poder: Pneumático
mídia: Ar Tamanho da porta: 1 1/2'1,5' de polegada
Estrutura: Diafragma Material do corpo: Liga de alumínio
Material do diafragma: NBR (Common), FKM (disponível) Número de diafragma: 1
Pressão: 0,1 a 0,8MPa Temperatura: -25 a +80 ℃
Destacar:

Pulse Valve G353A045

,

1.5'' Pulse Jet Valve

,

Pulse Diaphragm Valve

ASCO Type G353A045 G1-1/2'' Inch Remote Pilot Pulse Jet Diaphragm Valve


Single Stage, remote pilot, threaded body pulse valve.

The ASCO Type diaphragm pulse valves are especially designed for dust collector service applications, combining high flow, long life and extremely fast opening and closing to provide reliable and economical operation.

ASCO series 353 pulse valves are especially designed for dust collector service applications, combining high flow, long life and an extremely fast opening and closing to produce reliable and a economical operation. The valves comes with silencers to help reduce noise and prevent foreign particles from entering the valve.

ASCO Product Reference: G353A045


Technical Data of ASCO Pulse Jet Valve:


Port
Size
Remote Pilot Connection
Office Size
Operating Pressure Differential (Bar)
Model Number
Diaphragm Material
G
φB
(mm)
Min.
Max.
Aluminium



NBR/Viton
3/4''
1/8''
24
0.35
8.5
G353A041
1''
1/8''
27
0.35
8.5
G353A042
1 1/2''
1/8''
52
0.35
8.5
G353A045



Main Dimension:

ASCO Type G353A045 G1-1/2'' Inch Remote Pilot Pulse Jet Diaphragm Valve 0


353 Series Pulse Jet Valve For Dust Collector System:


Right Angle Valve
3/4''
1''
1 1/2''
2''
2 1/2''
SCG353A043
SCG353A044
SCG353A047
SCG353A050
SCG353A051
Submerged Valve
3''
SCEX353.060
Remote Pilot Valve
3/4''
1''
1 1/2''
G353A041
G353A042
G353A045


Our Production:

ASCO Type G353A045 G1-1/2'' Inch Remote Pilot Pulse Jet Diaphragm Valve 1
